VC 50
VC 50
The VC 50 is a small and compact 50 watt ultrasonic processor. The probe can be held by hand and ultrasonic energy is activated by turning the amplitude knob on the front panel.
The 1/8" probe (0.5 – 15mL volumes) is included with the VC 50 and a variety of accessories are available for various applications and sample volumes.
Part No. VC 50A can be used to order the system without the standard probe.
Features
- Compact design
- Variable power output
- Low cost
Specifications
Power Output
50 watt maximum
Frequency
20kHz
Dimensions
H x W x D: 8 x 8 x 5"
(203 x 203 x 127mm)
Converter Cable
Permanently attached
Length
5 ft. (1.5m)
Ultrasonic Converter
Part #CV18
Diameter
1.25" (32mm)
Length
5.75" (146mm)
Tool Kit
Part #888-00026 open end wrench (2 included)
Standard Probe
Part #630-0422
Tip Diameter
1/8" (3mm)
Length
5.4" (137mm)
Material
Ti6Al4V titanium alloy
Optional:
Stand with Clamp
Part #830-00460
Sound Enclosure
Part #830-00451
