Model 4300

Model 4300 Battery & Cell Test Equipment
Distributor & Service Provider In India

Inkarp Instruments, in collaboration with Maccor, brings the Model 4300 Battery and Cell Test Equipment to India, offering a high-performance testing solution for battery manufacturers and researchers. This advanced system provides unparalleled precision and flexibility, with features like multi-channel testing, high-speed data acquisition, and customizable test protocols, enabling Indian customers to optimize battery performance, safety, and reliability, supported by Inkarp Instruments' comprehensive sales, installation, and maintenance services.

The multifunction Model 4300 has all the power of Maccor’s Series 4000 floor standing cabinet conveniently packaged in a desktop cabinet.
The Model 4300 is supplied as a complete turnkey system with Tester PC and software. Powered by Maccor’s standard test system software and utilizing the same technology found in Maccor’s high-precision Series 4000 Automated Test System, the Model 4300 is the perfect mid-range desktop test system in Maccor’s line of high quality, dependable test systems.
The Model 4300 is supplied with a PowerPole® interface for easily connecting cables or cell holders. Each desktop cabinet is available with up to 8 test positions, however, test systems can have multiple test cabinets.
The Model 4300 can be configured with multi-current range channels, which have a current control range of 300 ηA to 5 A. These multi-current range channels can be configured for voltage ranges of -2V to +8V, 0V to +5V, or 0V to +10V as standard. The accuracy for current and voltage on these channels is ± 0.02% FSR. Alternately, the system can be configured with single current range channels, which can be configured for higher voltages and currents. The single current range channels have a current accuracy of ± 0.05% FSR and a voltage accuracy of ± 0.02% FSR.

Standard Features and Functions

Adaptable To A Wide Range Of Products (i.e. batteries, super-capacitors, fuel cells, etc.) And Battery Chemistries
Easily Scalable To Support Capacity Expansion At Acceptable Costs
Easy To Use And Maintain Minimizing Labor Force
Customizable To Meet Varying And Evolving Customer Requirements
Easily Adaptable To Meet A Wide Range Of Testing Needs
Each Test Station Operates Independently Of The Other Positions
Can Be User Programmed To Operate In Steps Of Constant Current, Constant Power, Constant Voltage, Constant Resistance, or Voltage Scan (Cyclic Voltammetry).
With the MIMS Client software, data is easily viewed graphically with different standard graphs. Several Chart types may be displayed at the same time with the ability to store the display settings as a template. Data from different devices may be overlaid on a single chart or viewed side-by-side.

The flexibility of the Model 4300 allows it to be used for a wide range of applications such as Materials Research, Portable Electronic Devices, Quality Control in Manufacturing, Medical Devices, Research & Development, Battery Pack Assembly, Battery and Cell Testing, Fuel Cell Testing, Super-Capacitor Testing, Thermal Battery Testing, Qualification Testing, and much much more.

Specifications

Current
Configuration	1, 2, 4, or 8 channels
Current Range	Per Your Specifications, currents up to 15 Amps available †
Maximum System Charge Current	Per Your Specification, up to 120 Amps
Minimum Full Scale Current	Per Your Specifications, 150 µAmps available
† Higher channel currents (up to a maximum of 120 Amps) can be supplied on systems with fewer channels.
Voltage
Minimum Measurement	-2 Volts ‡
Measurement Range	Per Your Specifications, voltages up to 96 volts available
‡ Lower minimum measurements can be attained. These would need to be discussed and agreed upon.
Power
Maximum System Charge Power	800 Watts
Maximum System Discharge Power	1200 Watts
Time
Minimum Step Time	10 mS*
Control, Measurement, and Adjustment	every 10 mS
* 4.6 mS Telecom Pulsing Feature As Standard
